Alternative DAS concept based on RLNC

Many thanks to Alex, Csaba, Dmitry, Mikhail and Potuz for fruitful discussions and write-up review

Abstract

The present DAS approach for Ethereum is based on Reed-Solomon erasure coding + KZG commitments. The novel scheme (described here Faster block/blob propagation in Ethereum by @potuz) introduces another pair: RLNC (Random Linear Network Coding) erasure coding + Pedersen commitments. It has nice properties which could be used to consider an alternative Data Availability approach.

The protocol outlined in this write-up primarily sketches what an RLNC-based Data Availability design might look like. The concepts used here are still not sufficiently checked, let alone formally proved. In any case if these concepts turn out to be correct, the algorithm could serve as a foundation for prototyping. If some of them turn out to be incorrect, we can either adjust the algorithm or think about adjusting or replacing them.

The reasoning in this write-up overlaps at several points with that of @Csaba’s recent post: Accelerating blob scaling with FullDASv2 (with getBlobs, mempool encoding, and possibly RLC).

_To explore the full context, including reasoning and discussion comments, see the extended version of this write-up: https://hackmd.io/@nashatyrev/Bku-ELAA1e_

Intro

Much like the write-up Faster block/blob propagation in Ethereum, the original data is split into NN vectors v_1, \dots, v_Nv1,…,vN over the field \mathbb{F}_pFp. These vectors can be coded using RLNC and committed via a Pedersen commitment (of size 32 \times N32×N) included in the block. Any linear combination can be verified given the commitment and its associated coefficients.
We also assume that the coefficients may come from a much smaller subfield \mathbb{C}_qCq, whose size could be as small as a single byte—or even a single bit (DISCLAIMER: from the latest discussions it’s not confirmed that we may have secure EC over a field with such a smaller subfield).

Let’s also introduce the sharding factor SS: any regular node needs to download and custody 1/S1/S of the original data size.

Having a fixed shard factor SS let’s take the total number of original vectors N = S^2N=S2

Brief protocol overview

A Pedersen commitment (size 32*N32∗N) is published in the corresponding block.

During dissemination each node receives pseudo-random linear combination vectors from its peers.

• this algorithm describes a non interactive approach where random coefficients are derived deterministicaly from the receiver’s nodeId and the RREF matrix trick is used (DISCLAIMER: the RREF trick isn’t strictly proved to work securely however there is an example which could be the proof starting idea)
• there is also an available fallback option: an interactive approach where the responder first reveals its source coefficients, and the requester then requests the linear combination using locally generated random coefficients.

Every sent linear combination vector is accompanied by basis vectors of the subspace this vector was randomly sampled from. These basis vectors must form a matrix in RREF form. This condition ensures that the remote peer indeed possesses basis vectors for the claimed subspace.

The node continues sampling until both of the following conditions are met:

• All received basis vectors span the full NN-dimensional space
• At least SS vectors for custody have been received

After that, the node completes sampling and becomes an ‘active’ node, which can be used for sampling by other nodes.

DA-RLNC.drawio796×1158 93.8 KB

Note

The below Python-like code snippets are for illustration purposes only, they are not intended to be compiled and executed for now. Some obvious or library-like functions lack their implementations so far.

Types

Let data vector elements be from a finite field \mathbb{F}_pFp which could roughly be mapped to 32 bytes

def FScalar

Let coefficients \mathbb{C}_qCq be from a subfield of (or equal to) \mathbb{F}_pFp

def CScalar

Let a single data vector has VECTOR_LEN elements from \mathbb{F}_pFp

def DataVector = Vector[FScalar, VECTOR_LEN]

Let the whole data be spit onto N original DataVectors:

def OriginalData = Vector[DataVector, N]

Derived DataVector is a linear combination of original DataVectors. Since an original vector is just a special case of a derived vector we will no longer make any distinctions between them.

To validate a DataVector against commitment its linear combination coefficients should be known:

def ProofVector = Vector[CScalar, N]

There is also a slightly different sequence of coefficents which is used when deriving a new vector from existing DataVectors:

def CombineVector = List[CScalar]

Structures

A data vector accompanied by the its linear combination coefficients

class DataAndProof:data_vector: DataVectorproof: ProofVector

The only message for dissemination is

class DaMessage:data_vector: DataVector# coefVector for validation is derivedorig_coeff_vectors: List[CombineVector]seq_no: Int

There is an ephemeral store for a block data:

class BlockDaStore:custody: List[DataAndProof]sample_matrix: List[ProofVector]# commitment is initialized first from the corresponding blockcommitment: Vector[RistrettoPoint]

Functions

Let the function random_coef generates a deterministically random coefficient vector with the seed (nodeId, seq_no):

def random_coef(node_id: UInt256, length: int, seq_no: int) -> CombineVector

Let’s define utility functions to compute linear combinations:

def linear_combination(vectors: Sequence[DataVector],coefficients: CombineVector) -> DataVectordef linear_combination(vectors: Sequence[ProofVector],coefficients: CombineVector) -> ProofVector

Function which performs linear operations on DataVectors and ProofVectors simultaneously to transform the ProofVectors to RREF:

def to_rref(data_vectors: Sequence[DataAndProof]) -> Sequence[DataAndProof]def is_rref(proofs: Sequence[ProofVector]) -> bool

The function creating a new deterministically random message from existing custody vectors for a specific peer:

def create_da_message(da_store: BlockDaStorereceiver_node_id: uint256,seq_no: int) -> DaMessage:rref_custody = to_rref(da_store.custody)rref_custody_data = [e.data_vector for e in rref_custody]rref_custody_proofs = [e.proof for e in rref_custody]rnd_coefs = random_coef(receiver_node_id, len(rref_custody), seq_no)data_vector = linear_combination(rref_custody_data, rnd_coefs)return DaMessage(data_vector, rref_custody_proofs, seq_no)

Computes the rank of data vectors’ coefficients. The rank equal to N means that the original data can be restored from the data vectors.

def rank(proof_matrix: Sequence[ProofVector]) -> int

Publish

The publisher should slice the data to vectors to get OriginalData.

Before propagating the data itself publisher should calculate Pedersen commitments (of size 32 * N), build and publish the block containing these commitments.

Then the publisher should populate custody with data vectors (original) and their ‘proofs’ which are simply elements of a standard basis: [1, 0, 0, ..., 0], [0, 1, 0, ..., 0]:

def init_da_store(data: OriginalData, da_store: BlockDaStore):for i,v in enumerate(data):e_proof = ProofVector([CScalar(1) if index == i else CScalar(0) for index in range(size)])da_store.custody += DataAndProof(v, eproof)

Publishing process is basically the same as the propagation process except the publisher sends by S messages to a single peer in a single round instead of sending just 1 message during propagation.

def publish(da_store: BlockDaStore, mesh: Sequence[Peer]):for peer in mesh:for seq_no in range(S):peer.send(create_da_message(da_store, peer.node_id, seq_no))

Receive

Assuming that the corresponding block is received and the BlockDaStore.commitment is filled prior receiving a message: DaMessage

Derive the ProofVector from original vectors:

def derive_proof_vector(myNodeId: uint256, message: DaMessage) -> ProofVector:lin_c = randomCoef(myNodeId,len(message.orig_coefficients),message.seq_no)return linear_combination(message.orig_coefficients, lin_c)

Validate

The message first validated:

def validate_message(message: DaMessage, da_store: BlockDaStore):# Verify the original coefficients are in Reduced Row Echelon Formassert is_rref(message.orig_coefficients)# Verify that the source vectors are linear independentassert rank(message.orig_coefficients) == len(message.orig_coefficients)# Validate Pedersen commitmentproof = derive_proof_vector(my_node_id, message)validate_pedersen(message.data_vector, da_store.commitment, proof)

Store

Received DataVector is added to the custody.
The sample_matrix is accumulating all the original coefficients and as soon as the matrix rank reaches N the sampling process is succeeded

def process_message(message: DaMessage, da_store: BlockDaStore) -> boolean:da_store.custody += DataAndProof(message.data_vector,derive_proof_vector(my_node_id, message))da_store.sample_matrix += message.orig_coefficientsis_sampled = N == rank(da_store.sample_matrix)return is_sampled

is_sampled == true means that we are [almost] 100% sure that our peers who sent us messages collectively posses 100% of information to recover the data.

Propagate

When the process_message() returns True, this means that the sampling was successful and the custody is filled with enough number of vectors. From now the node may start creating and propagating its own vectors.

We are sending a vector to every peer in the mesh which didn’t sent any vector to us yet:

# mesh: here the set of peers which haven't sent any vectors yet def propagate(da_store: BlockDaStore, mesh: Sequence[Peer]):for peer in mesh:peer.send(create_da_message(da_store, peer.node_id, 0))

Feasibility

Let’s overview some numbers depending on SS and |\mathbb{C}_q||Cq| (size of coefficients) assuming original data size of 32Mb32Mb:

According to these numbers it’s basically not feasible to use this algorithm with S \ge 64S≥64. If there are no options to use small coefficients (1 or 8 bits), then S = 8S=8 is the maximum sharding factor that makes sense due to the coefficient size overhead. (With S = 16S=16, the minimal node download throughput would be the same as with S = 8S=8.)

Pros and Cons

Pros

• The total data size to be disseminated, custodied and sampled is x1 (+ coefficients overhead which can be small if small coefficients are available) of the original data size (compared to x2 for PeerDAS and x4 for FullDAS)
• We potentially may have ‘shard factor’ SS as large as 32 (or probably even greater with some other modifications to the algorithm), which means every node needs to download and custody just 1/S1/S of the original data size. (v.s. 1/81/8 in the present PeerDAS approach: 8 columns from 64 original)
• Data is available and can be recovered by having just any SS regular honest nodes successfully performed sampling
• Sampling can be performed having any SS regular nodes (comparing to present DAS where a sampling node needs a variety of peers from distinct DAS subnets)
• The approach ‘what you sample is what you custody and serve’ (like PeerDAS subnet sampling but unlike full sharding peer sampling). The concerns regarding peer sampling approach described here
• Since no column slicing is involved separate blobs may just span several original data vectors and thus sampling process may potentially effectively benefit from EL blob transaction pool (aka engine_getBlobs())
• No smaller subnets which may be vulnerable to sybil attacks
• Duplication of data on the transport level could potentially be lower due to the fact that a node needs SS messages from any peers and the usage of RLNC coding
• RLNC + Pedersen could be less resource consuming than RS + KZG

Cons

• Commitment and proof size grow quadraticaly with sharding coefficient SS.
• If smaller coefficients are not available (not proved to be secure) then just S=8S=8 is feasible.
• Still need to estimate dissemination latency as a node may propagate data only after it completes its own sampling
• For happy case the minimal number of peers for sampling is 32 (comparing to 8 in PeerDAS)

Statements to be proved

The above algorithm relies on a number of [yet fuzzy] statements which need to be proved so far:

1. A valid linear combination with requested random coefficients returned by a super-node proves that the responding node has access to the full data (enough vectors to recover). This statement doesn’t look that tricky to prove
2. If a full-node claims it has basis vectors which form a coefficient subspace, then if a node requests a random vector from this subspace and get a valid data vector then it proves the responding node indeed has the basis vectors for the claimed subspace. The proof could be a generalization of the statement (1)
3. An EC over \mathbb{F}_pFp with subfield \mathbb{C}_2C2 makes sense and is secure. (this doesn’t seem to be true according to the latest discussions)
4. The trick with RREF basis form for zero-RRT sampling actually works.
   (this example can give some intuition about the validity of this statement)
5. The described algorithm yields evenly distributed basis vectors across hones nodes for the full N-dimensional space. There a pretty small E (kind of 1-3) such that the rank of basis vectors of any randomly selected S + E nodes would be N with some ‘very high’ probability . The same should be true in a Byzantine environment
